20cm MSL 1000D Reinforced Drop Stitch
This 20 cm MSL model is a 2700 GSM drop stitch PVC fabric with 1000D × 1000D yarns and a 2.03 m width. It is a candidate for broad mattress and inflatable-pool panels that need a documented reinforced construction rather than a material selected only by chamber height.
The query 1000 denier reinforced drop stitch describes a buying need, not a complete specification. MSL is the catalog designation on this page; the actual face layers, laminate route and reinforcement must be confirmed on the approved cross-section and data sheet.
Ordering Specification
| Item | Approved Ordering Basis |
|---|---|
| Finished height | 20 cm |
| Yarn structure | 1000D × 1000D |
| Nominal weight | 2700 GSM |
| Roll width | 2.03 m |
| Surface pattern | Dot |
| PVC formulation | Airtight |
| Catalog designation | MSL; confirm the actual layer build |
| Color | Multiple options after sample approval |
| Reference uses | Mattress and inflatable-pool panels |
| B2B MOQ | 5,000 m² |
Define the MSL Build before Quoting Performance
Ask for the layer sequence, bonding route and location of any added skin. If a sample is described as monocoque structural laminate, make that definition part of the purchase specification rather than relying on the acronym alone.
For an inflatable pool, provide wall dimensions, corner geometry, water depth, external supports and access details. A pool wall and an air mattress impose different loads even when both use a 20 cm chamber.
Test Lamination, Welds and the Finished Chamber
Include peel or adhesion checks where relevant, plus seam qualification, pressure retention and visual inspection after folding. Test methods, sample direction and acceptance limits must be agreed because numbers from different methods cannot be compared directly.
For bulk release, retain the approved cross-section, color, welding setup and finished-panel record. Recheck any change in adhesive, surface, layer sequence or edge-band material before applying it to the production order.
Place 20cm MSL 1000D Reinforced Drop Stitch beside the other heights and constructions in our Drop Stitch Fabrics collection before final selection.
FAQ
What does MSL guarantee?
The acronym alone guarantees nothing beyond the catalog label. Confirm the physical layer build and the tests linked to the buyer’s application.
Is this material automatically suitable for an inflatable pool?
No. Pool geometry, water load, supports, seams, valves and safety requirements must be engineered and tested as a finished system.
Can LonaTarp supply welded panels?
Yes, subject to drawing review, seam qualification, dimensional tolerance and approval of a representative component.
When does the 5,000 m² MOQ apply?
It applies to the normal customized B2B production order after the MSL construction and sample acceptance record are fixed.
Request an MSL Cross-Section Review
Send the layer description, application drawing, pressure and load conditions, weld design, color and quantity. We will separate verified construction facts from assumptions before preparing the sample plan.
