20cm Wide Drop Stitch Inflatable Material
This wide drop stitch inflatable material combines a 20 cm chamber, 2.03 m roll width and 2800 GSM, 500D × 500D construction. It is aimed at large panels where reducing a longitudinal join may improve layout or assembly efficiency.
A 2.03 m roll only creates value if the buyer can handle it. Unwind space, cutting-bed width, welding reach, roll weight and export packing should be checked before choosing the wide format.
Ordering Specification
| Item | Approved Ordering Basis |
|---|---|
| Finished height | 20 cm |
| Yarn structure | 500D × 500D |
| Nominal weight | 2800 GSM |
| Roll width | 2.03 m |
| Surface pattern | Dot |
| PVC formulation | Airtight |
| Color | Selected against an approved sample |
| Printing | Requires a separate process review |
| Supply form | Rolls, cut panels or drawing-based fabrication |
| B2B MOQ | 5,000 m² |
Audit the Converting Line before Buying Wide Rolls
Map the complete material path from container unloading to final weld. A roll that fits the panel may still be impractical if it cannot pass through the customer’s rack, cutter or welding station.
Use the finished drawing to compare one-piece yield with a narrower multi-panel design. Removing a seam can save labor, but only when trim loss and handling time do not erase the benefit.
Prove Large-Panel Behavior at Finished Scale
The 2800 GSM value is not a stand-alone strength guarantee. Test the intended panel dimensions, edge construction, pressure, hold time and allowable deformation. Larger areas may reveal shape or seam issues that a small coupon cannot show.
Agree how rolls will be wound, protected, labeled and lifted. For pre-cut supply, include datum points and orientation marks so large parts can be located consistently during assembly.
Place 20cm Wide Drop Stitch Inflatable Material beside the other heights and constructions in our Drop Stitch Fabrics collection before final selection.
FAQ
Will a 2.03 m width remove every panel join?
Not necessarily. Finished size, seam allowance, edge design and part orientation determine whether a one-piece layout is possible.
Can you deliver cut 20 cm panels?
Yes, after drawing revision, tolerance, marking, packing and the customer’s assembly sequence are confirmed.
Is 2800 GSM always stronger than 2200 GSM?
No. Different yarn, coating and construction routes cannot be ranked by weight alone; compare agreed test data.
How is MOQ handled for wide material?
The standard production minimum is 5,000 m², and packing details should be fixed before the bulk run.
Check Your 2.03 m Handling Route
Send the panel size, equipment limits, weld layout, roll core preference and unloading method. Our team can compare roll supply with cut-panel fabrication before pricing the 20 cm program.
